Product Details:
Payment & Shipping Terms:
|
| Features: | The Grass Surface Is Plump, Wear-resistant, And Has Good Stiffness | Item: | Football Grass |
|---|---|---|---|
| Application: | Football | Colour: | Field Green + Tender Green (same Hole) |
| Code: | DM400 | Height: | 40-60mm |
| Roll Width: | 4.0m/2.0m | Detex: | 13200 |
| Stitches Per M2: | 10080±100 | Backing: | PP+Leno |
Football Grass Artificial Grass Turf For Football Field 40mm 50mm 60mm
This grass is AVG’s ALL STAR grass, meeting the requirements of FIFA Quality Pro. The unique diamond design with thick fibers of 360 Microns provide excellent abrasion resistance. It is a perfect combination of outstanding sports performance, durability and high resilence. The patented low sliding resistance design reduces athletes injury, and improves athletes’ performance.
Key benefits:
| PRODUCT SPECIFICATION | |||
| Product name: | AVG DM400 | Application: | Football |
| Model: | AF50416DM132B5 | Roll width: | 4.0m/2.0m |
| Color: | Field&Light green Bi-color | Roll length: | On request |
| Accreditations | FIFA Quality Pro | Warranty: | 8 years under AVG warranty terms |
| YARN CHARACTERISTICS | |||
| Yarn 1 | |||
| Structure: | Monofilament | ||
| Composition: | PE | ||
| Dtex: | 13200 | ||
| Yarn thickness: | 360±20μm | ||
| Yarn width: | 1.0±0.1mm | ||
| UV Effects | |||
| Yarn color fastness: | Grey scale ≥4 | UV stability | ＞5000hrs |
| CARPET CHARACTERISTICS | |||
| TURF | |||
| Pile height: | 40-60mm±2mm | Gauge: | 5/8inch |
| Number of strands per tuft: | 6 strands | Stitches per 10cm: | 16±1 |
| Stitches per m2 | 10080±100 | Total yarn weight: | 1467g/sqm ±10% |
| BACKING | |||
| Primary backing: | PP+Leno | ||
| Weight: | 171g/sqm | ||
| Latex weight: | 1100g/sqm ±10% | ||
| Total carpet weight: | 2738g/sqm ±100g/sqm | ||
| Carpet | |||
| Carpet tuft withdrawal: | ≥30N | Water permeability of carpet: | ＞180mm/hr |
| INFILL REQUIREMENTS | |||
| Sand | |||
| Particle size range | 0.5-1.0mm | Particle shape: | Round |
| Bulk density | 1.28g/cm3 | Application rate: | 25kg/sqm |
| SBR | |||
| Particle size range: | 1.25-2.0mm | Particle shape: | Irregular |
| Bulk density: | 0.36g/cm3 | Application rate: | 6kg/sqm |
| SHOCK-PAD OR ELASTIC LAYER | |||
| SEPP 17MM Plus | |||
| Thickness | 17mm | Shock absorption | 60% |
AVG Company Profile:
Efficient Production Capacity
Equipped with totally 30 automatic production lines with advanced manufacturing faclities that yield
annual production capacity up to 20 million square meters of artificial turf.
Hi-tech R&D
3 R&D Centers in China and USA, cooperating with world-class universities to provide products in high quality and excellent performance as per the synchronized design in international trend.
Fine Raw Materials
Extremely stringent in the selection of raw materials. PE raw materials are imported from Sabic Saudi Arabia and Dow Canada. SBR latex is sourced from Dow US and BASF Germany.
OurService:
Sample Service | We provide free sample for confirmation and customer bears the freight charges. |
Customized Service | We provide professional customized service, namely, we are capable of providing the specific product you want, no matter for logo, material, size, color, etc. |
After-sales Service | Our enthusiastic and friendly customer service representatives are ready to assist with any questions or problems. |
